| Name: | Automatic Coil Winding Machine | Max. Winding Width: | 1200mm |
|---|---|---|---|
| Winding Power: | 5.5kw | Winding Speed: | 0 ~ 80rpm |
| Servo Motor: | 0.75kw | Wire Guide: | 1 Pc |
| Color: | As Requested | Warranty: | 12 Months |
| Highlight: | Copper auto transformer winding machine,Automatic Coil Winding Machine,Transformer Copper Wire Winder |
||
Máquina de bobinado Transformer Copper Wire Winder Automatic Coil Winding Machine
Description of automatic coil winding machine ZPX1200
Automatic coil winding machine is a professional copper wire or aluminium wire winder. The automatic coil winding machine is mainly used to wind transformer coils or other similar products. The automatic coil winding machine can wind both copper wires and aluminium wires. With one servo motor, the coil winding machine can drive the wire guide move precisely to lay wire. The automatic coil winding machine is also provided with PLC and a touch screen, which makes the coil winding machine have high automation. The coil winding machine features slow starting, smooth running, high torque, and easy operation etc.
Features of automatic coil winding machine ZPX1200
Main Parameters of automatic coil winding machine ZPX1200
The following is the standard specifications of automatic coil winding machine ZPX1200 and the machine can also be manufactured as requested.
| Center Height From Floor: | 900mm |
| Winding Square Shaft Size: | 50x50x1500mm |
| Maximum Winding Width: | 1200mm |
| Winding Power: | 5.5kw |
| Winding Speed: | 0 ~ 160 rpm |
| Regulation: | stepless speed regulation |
| Max. Flat Wire Size: | 5X12mm |
| Round Wire Diameter: | Φ0.3mm ~ Φ5.0mm |
| Maximum wound Coil OD.: | Φ800mm |
| Maximum Capacity: | 800kg |
| Counting Mode: | 5-digit counting |
| Max. Numbers of Turns Preset: | 9999.9 |
| Counting Turn Range: | 0 ~ 9999.9 |
Fig 1: Automatic coil winding machine ZPX1200's front view
Fig 2: Automatic coil winding macihne ZPX1200's side view
