Product Details:
Payment & Shipping Terms:
|
| Product Name: | Motor Coil Winding Machine | Machine Color: | Optional |
|---|---|---|---|
| Rotate Speed: | 0 ~ 200rpm | Flange Diameter: | 500mm |
| Speed Regulation: | Stepless | Conduct Type: | Copper Or Aluminium Wire |
| Warranty: | 12 Months | Winding Power: | 3kw |
| Highlight: | Electric Motor Coil Winding Machine,Copper Wire Coil Winding Machine,Semi Automatic Coil Winding Machine |
||
Semi Automatic Copper Wire Winder Electric Motor Coil Winding Machine
Description of motor coil winding machine MW500
Motor coil winding machine MW-500 is one kind of semi automatic wire winder. The motor coil winding machine is mainly for winding motor coils and other similar products. The motor coil winding machine is provided with a flange with diameter 500mm, and a mold can be fixed on the flange. The motor coil winding machine is provided with a foot pedal, with it, the rotating direction of the motor coil winding machine can be switched. The motor coil winding machine features easy operation and so on.
Details of motor coil winding machine MW500
Main Parameters
Typical standard specifications of motor coil winding machine MW500 are shown below and the motor coil winding machine can also be manufactured as requested.
| Machine Height: | 1400mm |
| Flange Diameter: | Ø500mm |
| Rotating Speed: | 0 ~ 200rpm |
| Counting Range: | 0 ~ 9999.9 |
| Max. Capacity: | 200KG |
| Main motor Power: | 3KW |
| Colour: | customized |
| Machine Dimension(L*W*H): | 900 x 700 x 1400mm |
Fig 1: Motor coil winding machine MW500's full view
Fig 2: Motor coil winding machine MW500's control board
