Product Details:
Payment & Shipping Terms:
|
| Name: | Transformer Core Stacking Table | Function: | Stacking Transformer Iron Core |
|---|---|---|---|
| Maximum Capacity: | 3000kg, Maximum | Lift Stoke: | 300mm, Maximum |
| Motor Power: | 2.2kw | Machine Color: | As Requested |
| Driven: | Hydraulic | Warranty Period: | One Year |
| Highlight: | Tilting Transformer Core Stacking Table,Amorphous Transformer Core Stacking Table,Lap Core Transformer Core Stacking Table |
||
Lap Core Stacking And Tilting Table Amorphous Transformer Core Stacking Table
Description of transformer core stacking table ZPT-3T
Transformer core stacking table ZPT-3T is a professional stacking equipment, which is mainly for assembling amorphous alloy transformer iron cores. The transformer core stacking table is provided with a hand held controller, which can be operated easily. With a hydraulic station, the transformer core stacking table can tilt the stacked core. The core stacking table features easy operation, smooth running and so on.
Quick details of transformer core stacking table ZPT-3T
Main Parameters of transformer core stacking table ZPT-3T
Typical standard specifications of transformer core stacking table ZPT-3T are shown below and the core stacking table can also be manufactured as requested.
| Working height | 850mm |
| Applicable Product Size |
L:700-1600mm W:360-700mm H:400-900 |
| Lifting Platform Capacity (rated) | 3000Kg |
| Lifting Platform Stroke | 300mm |
| Lifting Speed | 40mm/s |
| Total Power | 2.2Kw |
| Total Weight | 1500Kg |
| Applicable Transformer capacity | 30KVA-2000KVA |
| Rotating Angle | 90° |
| Hydraulic Working Pressure | 21MPa |
Fig 1: Transformer core stacking table ZPT-3T's full view
Fig 2: Transformer core stacking table ZPT-3T's tilting
